Fill-Rite ARCH10020A 3/4" x 20' (6 m) Arctic Fuel Transfer Hose

Model/SKU: ARCH07520A
Manufacturer Part # ARCH07520A

Description

The Fill-Rite ARCH07520A is a 3/4 inch by 20 foot (6 m) sub-zero fuel transfer hose with 3/4 inch NPT ends. It is built for cold-weather fueling on tanks, trucks, and transfer pumps when a standard hose would stiffen or crack.

The 2026 Fill-Rite catalog rates this hose from -70 degrees F to 212 degrees F (-56 degrees C to 100 degrees C), well below a standard fuel hose, and to 50 PSI (3.4 bar). A nitrile inner tube stands up to everyday fuel service, a neoprene cover resists abrasion and weather, an internal spring guard reduces kinking, and an anti-static ground wire runs the length of the hose. It carries a 1-year warranty. Certifications are not listed for this model.

Key Specs
  • Model: ARCH07520A
  • Size: 3/4" ID x 20' (6 m); 1.2" OD
  • Ends: 3/4" NPT both ends
  • Construction: Nitrile inner tube, neoprene cover, internal spring guard, full-length anti-static ground wire
  • Max working pressure: 50 PSI / 3.4 bar
  • Operating temperature: -70 degrees F to 212 degrees F (-56 degrees C to 100 degrees C)
  • Compatible fluids: Diesel, gasoline, biodiesel up to B20, and mineral spirits
  • Certifications: None listed
  • Warranty: 1 year
Common Uses

Replacing or adding a 3/4 inch discharge hose on fuel transfer pumps used in cold climates, where the hose needs to stay flexible down to -70 degrees F for diesel, gasoline, and other listed fuels.
