Fill-Rite ARCH10020A 1" x 20' (6 m) Arctic Fuel Transfer Hose

Model/SKU: ARCH10020A
Manufacturer Part # ARCH10020A

Description

The Fill-Rite ARCH10020A is a 1 inch by 20 foot (6 m) sub-zero fuel transfer hose with 1 inch male NPT ends. It is built for cold-weather fueling on tanks, trucks, and transfer pumps when a standard hose would stiffen or crack.

Fill-Rite rates this hose from -70 degrees F to 212 degrees F (-56 degrees C to 100 degrees C) and to 50 PSI (3.4 bar). A nitrile inner tube stands up to everyday fuel service, a neoprene cover resists abrasion and weather, an internal spring guard reduces kinking, and a stainless steel ground wire runs the full length of the hose to help control static buildup. It carries a 1-year warranty. Certifications are not listed for this model.

Key Specs
  • Model: ARCH10020A
  • Size: 1" ID x 20' (6 m); 1.5" OD
  • Ends: 1" male NPT both ends
  • Construction: Nitrile inner tube, neoprene cover, internal spring guard, full-length stainless steel ground wire
  • Max working pressure: 50 PSI / 3.4 bar
  • Operating temperature: -70 degrees F to 212 degrees F (-56 degrees C to 100 degrees C)
  • Compatible fluids: Diesel, gasoline, kerosene, biodiesel up to B20, ethanol blends up to E15, and light oils
  • Package weight: 10.25 lbs
  • Certifications: None listed
  • Warranty: 1 year
Common Uses

Replacing or adding a 1 inch discharge hose on fuel transfer pumps used in cold climates, where the hose needs to stay flexible down to -70 degrees F for diesel, gasoline, and other listed fuels.
