Fill-Rite FR710VB 115 Volt AC High Flow Pump with Hose and Nozzle - 20 GPM

Model/SKU: FR710VB
Manufacturer Part # FR710VB

Description

The Fill-Rite FR710VB is a 115V AC, 20 GPM (75 LPM) heavy-duty rotary vane pump with a 1 inch outlet for the higher-flow hose kit. It ships with a 1 inch by 18 foot UL listed discharge hose with static ground wire and a 1 inch ultra high-flow automatic diesel nozzle (green).

The FR710VB uses the same 0.33 HP, 5.5 A, thermally protected 115V motor as the rest of the FR700 family, with a 30 minutes on / 30 minutes off duty cycle, 15 feet of suction lift, and 53 feet of discharge head (23 PSI). Inlet is 1.25 inch female NPT; outlet is 1 inch female NPT. Compatible fluids are diesel, kerosene, biodiesel up to B20, gasoline up to E15, mineral spirits, heptane, and Stoddard solvents. The pump is cULus certified and is backed by a Limited Lifetime warranty.

Key Specs
  • Model: FR710VB
  • Max flow rate: 20 GPM / 75 LPM
  • Power: 115V AC, 5.5 A; 0.33 HP thermally protected motor
  • Duty cycle: 30 min on / 30 min off
  • Inlet / outlet: 1.25 inch female NPT inlet / 1 inch female NPT outlet
  • Mounting: 2 inch NPT bung mount
  • Suction lift / discharge: 15' suction lift; 53' discharge head (23 PSI)
  • Compatible fluids: Diesel, kerosene, biodiesel up to B20, gasoline up to E15, mineral spirits, heptane, Stoddard solvents
  • Included: 1" x 18' UL listed hose with static ground wire, 1" ultra high-flow automatic diesel nozzle (green), nozzle boot, PTFE tape, 1" NPT street elbow, locking nut, fastener; hard-wired electrical connection
  • Assembled weight: 57.2 lbs
  • Warranty: Limited Lifetime
  • Certifications: cULus
Common Uses

115V tank installations that need a 20 GPM pump with a 1 inch automatic diesel nozzle and a longer 18 foot hose, such as larger farm or fleet equipment.



Detailed Information

PDF  FR710VB Manual
Fill-Rite
Fill-Rite Warranty Details:

PDF  Fill-Rite Warranty
